Säädettävä LED-vakiojänniteteholähde Mean Well HLG-320H-24A
Säädettävä LED-vakiojänniteteholähde Mean Well HLG-320H-24A
Mean Well HLG-320H-24A on 320 watin LED-vakiojännitelähde, joka tarjoaa vakaan 24V DC -lähtöjännitteen. Sen lähtöjännitettä ja -virtaa voidaan säätää sisäänrakennettujen potentiometrien avulla, mikä mahdollistaa joustavan käytön erilaisissa LED-valaistussovelluksissa.
Lisätietoja
Lisätietoja
<h3 data-start="2587" data-end="2608"><strong data-start="2591" data-end="2608">Käyttökohteet</strong></h3>
<p data-start="2610" data-end="2695"><span class="relative -mx-px my-[-0.2rem] rounded px-px py-[0.2rem]">HLG-320H-24A soveltuu monenlaisiin LED-valaistussovelluksiin, kuten:</span></p>
<ul data-start="2697" data-end="2925">
<li data-start="2697" data-end="2722"><strong data-start="2699" data-end="2720">LED-katuvalaistus</strong></li>
<li data-start="2723" data-end="2765"><strong data-start="2725" data-end="2763">LED-teollisuusvalaistus (high-bay)</strong></li>
<li data-start="2766" data-end="2802"><strong data-start="2768" data-end="2800">Pysäköintialueiden valaistus</strong></li>
<li data-start="2803" data-end="2828"><strong data-start="2805" data-end="2826">LED-kalastusvalot</strong></li>
<li data-start="2829" data-end="2860"><strong data-start="2831" data-end="2858">LED-kasvihuonevalaistus</strong></li>
<li data-start="2861" data-end="2925"><strong data-start="2863" data-end="2923">Tyyppi "HL" käyttöön luokan I, Division 2 -sovelluksissa</strong></li>
</ul>
Tekniset tiedot
Tekniset tiedot
<table data-start="318" data-end="2580">
<thead data-start="318" data-end="401">
<tr data-start="318" data-end="401">
<th data-start="318" data-end="352"><strong data-start="320" data-end="334">Ominaisuus</strong></th>
<th data-start="352" data-end="401"><strong data-start="354" data-end="362">Arvo</strong></th>
</tr>
</thead>
<tbody data-start="486" data-end="2580">
<tr data-start="486" data-end="622">
<td><span class="relative -mx-px my-[-0.2rem] rounded px-px py-[0.2rem]"><strong data-start="0" data-end="9" data-is-last-node="" data-is-only-node="">Malli</strong></span></td>
<td><span class="relative -mx-px my-[-0.2rem] rounded px-px py-[0.2rem]">HLG-320H-24A</span></td>
</tr>
<tr data-start="623" data-end="751">
<td><span class="relative -mx-px my-[-0.2rem] rounded px-px py-[0.2rem]"><strong data-start="0" data-end="9" data-is-last-node="" data-is-only-node="">Mitat</strong></span></td>
<td><span class="relative -mx-px my-[-0.2rem] rounded px-px py-[0.2rem]">244,2 x 68 x 38,8 mm</span></td>
</tr>
<tr data-start="752" data-end="877">
<td><span class="relative -mx-px my-[-0.2rem] rounded px-px py-[0.2rem]"><strong data-start="0" data-end="15" data-is-last-node="" data-is-only-node="">Tulojännite</strong></span></td>
<td><span class="relative -mx-px my-[-0.2rem] rounded px-px py-[0.2rem]">90–305V AC, 47–63Hz</span></td>
</tr>
<tr data-start="878" data-end="982">
<td><span class="relative -mx-px my-[-0.2rem] rounded px-px py-[0.2rem]"><strong data-start="0" data-end="16" data-is-last-node="" data-is-only-node="">Lähtöjännite</strong></span></td>
<td><span class="relative -mx-px my-[-0.2rem] rounded px-px py-[0.2rem]">24V DC (säädettävissä 22,4–25,6V välillä)</span></td>
</tr>
<tr data-start="983" data-end="1085">
<td><span class="relative -mx-px my-[-0.2rem] rounded px-px py-[0.2rem]"><strong data-start="0" data-end="14" data-is-last-node="" data-is-only-node="">Lähtövirta</strong></span></td>
<td><span class="relative -mx-px my-[-0.2rem] rounded px-px py-[0.2rem]">Enintään 13,34A (säädettävissä 6,67–13,34A välillä)</span></td>
</tr>
<tr data-start="1086" data-end="1201">
<td><span class="relative -mx-px my-[-0.2rem] rounded px-px py-[0.2rem]"><strong data-start="0" data-end="20" data-is-last-node="" data-is-only-node="">Tehokerroin (PF)</strong></span></td>
<td><span class="relative -mx-px my-[-0.2rem] rounded px-px py-[0.2rem]">≥0,95 (täydellä kuormalla)</span></td>
</tr>
<tr data-start="1202" data-end="1337">
<td><span class="relative -mx-px my-[-0.2rem] rounded px-px py-[0.2rem]"><strong data-start="0" data-end="14" data-is-last-node="" data-is-only-node="">Hyötysuhde</strong></span></td>
<td><span class="relative -mx-px my-[-0.2rem] rounded px-px py-[0.2rem]">Enintään 94%</span></td>
</tr>
<tr data-start="1338" data-end="1481">
<td><span class="relative -mx-px my-[-0.2rem] rounded px-px py-[0.2rem]"><strong data-start="0" data-end="16" data-is-last-node="" data-is-only-node="">Dimmattavuus</strong></span></td>
<td><span class="relative -mx-px my-[-0.2rem] rounded px-px py-[0.2rem]">Ei</span></td>
</tr>
<tr data-start="1482" data-end="1610">
<td><span class="relative -mx-px my-[-0.2rem] rounded px-px py-[0.2rem]"><strong data-start="0" data-end="11" data-is-last-node="" data-is-only-node="">Elinikä</strong></span></td>
<td><span class="relative -mx-px my-[-0.2rem] rounded px-px py-[0.2rem]">Enintään 62 000 tuntia</span></td>
</tr>
<tr data-start="1611" data-end="1740">
<td><span class="relative -mx-px my-[-0.2rem] rounded px-px py-[0.2rem]"><strong data-start="0" data-end="19" data-is-last-node="" data-is-only-node="">Käyttölämpötila</strong></span></td>
<td><span class="relative -mx-px my-[-0.2rem] rounded px-px py-[0.2rem]">-40°C – +70°C</span></td>
</tr>
<tr data-start="1741" data-end="1884">
<td><span class="relative -mx-px my-[-0.2rem] rounded px-px py-[0.2rem]"><strong data-start="0" data-end="17" data-is-last-node="" data-is-only-node="">Suojausluokka</strong></span></td>
<td><span class="relative -mx-px my-[-0.2rem] rounded px-px py-[0.2rem]">I</span></td>
</tr>
<tr data-start="1885" data-end="2022">
<td><span class="relative -mx-px my-[-0.2rem] rounded px-px py-[0.2rem]"><strong data-start="0" data-end="20" data-is-last-node="" data-is-only-node="">Kotelointiluokka</strong></span></td>
<td><span class="relative -mx-px my-[-0.2rem] rounded px-px py-[0.2rem]">IP65</span></td>
</tr>
<tr data-start="2023" data-end="2128">
<td><span class="relative -mx-px my-[-0.2rem] rounded px-px py-[0.2rem]"><strong data-start="0" data-end="11" data-is-last-node="" data-is-only-node="">Suojaus</strong></span></td>
<td><span class="relative -mx-px my-[-0.2rem] rounded px-px py-[0.2rem]">Oikosulku-, ylijännite-, ylikuormitus- ja ylikuumenemissuoja</span></td>
</tr>
<tr data-start="2129" data-end="2255">
<td><span class="relative -mx-px my-[-0.2rem] rounded px-px py-[0.2rem]"><strong data-start="0" data-end="15" data-is-last-node="" data-is-only-node="">Hyväksynnät</strong></span></td>
<td><span class="relative -mx-px my-[-0.2rem] rounded px-px py-[0.2rem]">UL, CUL, TUV, CE, CB</span></td>
</tr>
<tr data-start="2256" data-end="2389">
<td><span class="relative -mx-px my-[-0.2rem] rounded px-px py-[0.2rem]"><strong data-start="0" data-end="23" data-is-last-node="" data-is-only-node="">RoHS-yhteensopivuus</strong></span></td>
<td><span class="relative -mx-px my-[-0.2rem] rounded px-px py-[0.2rem]">Kyllä</span></td>
</tr>
<tr data-start="2390" data-end="2580">
<td><span class="relative -mx-px my-[-0.2rem] rounded px-px py-[0.2rem]"><strong data-start="0" data-end="9" data-is-last-node="" data-is-only-node="">Takuu</strong></span></td>
<td><span class="relative -mx-px my-[-0.2rem] rounded px-px py-[0.2rem]">7 vuotta</span></td>
</tr>
</tbody>
</table>
Datalehti
Datalehti
- Lataa tiedostoHLG-320H-24-rpt.pdf
- Lataa tiedostoHLG-320H-spec.pdf
- Lataa tiedostoE334687-UL-cer.pdf
- Lataa tiedostoHLG-320H-CB-cer.pdf
- Lataa tiedostoHLG-320H-CE-dec.pdf
- Lataa tiedostoHLG-320H-EMC-cer.pdf
- Lataa tiedostoHLG-320H-XC-TUV-cer.pdf
Käyttöohje
Käyttöohje
- Lataa tiedostoLED EN.pdf
